Perfect for digging ditches and finishing tasks!
Like all Cotech buckets, the ditch buckets are equipped with our reversible ears which allow excavation in reverse mode. They are made of high-strength Hardox® 450 steel, which ensures unfailing durability. No matter the make or model of your excavator, we have the bucket you need because they are available in different heights or widths. They are equipped as standard with a reversible bolted cutting edge which protects the shell and the main cutting edge from wear. Robotic welding is at the heart of our processes, which ensures consistency in the manufacturing of our buckets.
10-200 HP
| EGF | ||||||||
| Models | Capacity | Height | Width | Weight | Attach Style | Excavator Weight | ||
| EGF1RA-1024 | 0.04 yd3 | 10" | 24" | 82 lbs | As required | 0.5 to 1 ton | ||
| EGF1RA-1030 | 0.05 yd3 | 10" | 30" | 98 lbs | As required | 0.5 to 1 ton | ||
| EGF1RA-1324 | 0.05 yd3 | 13" | 24" | 93 lbs | As required | 1 to 1.9 tons | ||
| EGF1RA-1330 | 0.06 yd3 | 13" | 30" | 108 lbs | As required | 1 to 1.9 tons | ||
| EGF2RA-1736-C | 0.15 yd3 | 17" | 36" | 224 lbs | As required | 2 to 2.9 tons | ||
| EGF3RA-1736-C | 0.15 yd3 | 17" | 36" | 224 lbs | As required | 2.5 to 3 tons | ||
| EGF3RA-1936-C | 0.18 yd3 | 19" | 36" | 251 lbs | As required | 3 to 3.8 tons | ||
| EGF3RA-2142-C | 0.25 yd3 | 21" | 42" | 334 lbs | As required | 3.9 to 4.9 tons | ||
| EGF3RA-2442-C | 0.36 yd3 | 24" | 42" | 387 lbs | As required | 5 to 7 tons | ||
| EGF3RA-2448-C | 0.41 yd3 | 24" | 48" | 425 lbs | As required | 5 to 7 tons | ||
| EGF4RA-2648-C | 0.48 yd3 | 26" | 48" | 614 lbs | As required | 7 to 10 tons | ||
| EGF4RA-2654-C | 0.54 yd3 | 26" | 54" | 668 lbs | As required | 7 to 10 tons | ||
| EGF4RA-2660-C | 0.60 yd3 | 26" | 60" | 719 lbs | As required | 7 to 10 tons | ||
| EGF5RA-3460-C | 0.82 yd3 | 34" | 60" | 1,257 lbs | As required | 10 to 16 tons | ||
| EGF6RA-4272-C | 1.56 yd3 | 42" | 72" | 2,122 lbs | As required | 17 to 23 tons | ||
| EGF6RA-4672-C | 1.83 yd3 | 46" | 72" | 2,494 lbs | As required | 24 to 27 tons | ||
